| Peripheral | |
Accessory Port | NATO Ports |
| 1/4″-20 Mounting Hole |
| Cold Shoe |
| Video Transmission/Focus Motor Port (USB-C) |
| RSS Camera Control Port (USB-C) |
| Focus Motor Port (USB-C) |
Battery | Model: BHX711-3000-7.2V |
| Type: 2S |
| Capacity: 3000 mAh |
| Energy: 21 Wh |
| Max. Runtime: 12 hours [1] |
| Charging Time: Approx. 2.5 hours when using 18W quick charging (supports PD protocol) |
| Suggested Charging Temperature: 5° to 40° C (41° to 104° F) |
Connections | Bluetooth 5.0 |
| Charging Port (USB-C) |
Ronin App Requirements | iOS 11.0 or above |
| Android 7.0 or above |
Languages Supported by the Touchscreen | English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai |
Working Performance | |
Tested Payload | 3 kg (6.6 lbs) |
Maximum Controlled Rotation Speed | Pan: 360°/s |
| Tilt: 360°/s |
| Roll: 360°/s |
Mechanical Range | Pan axis: 360° continuous rotation |
| Roll axis: -95° to +240° |
| Tilt axis: -112° to +214° |
Mechanical & Electrical Properties | |
Operating Frequency | 2.400-2.484 GHz |
Bluetooth Transmitter Power | <8 dBm |
Operating Temperature | -20° to 45° C (-4° to 113° F) |
Weight | Gimbal: Approx. 990 g (2.18 lbs) |
| Grip: Approx. 200 g (0.44 lbs) |
| Extended Grip/Tripod (Plastic): Approx. 183 g (0.4 lbs) |
| Upper and Lower Quick-Release Plates: Approx. 107 g (0.23 lbs) |
Dimensions | Folded: 254×230×68 mm (L×W×H, excluding camera, grip, and the Extended Grip/Tripod) |
| Unfolded: 364×187×170 mm (L×W×H, height includes the grip and excludes the Extended Grip/Tripod) |
DJI Ronin Image Transmitter | |
Connections | Power/Communication Port (USB-C) |
| HDMI Port (Mini HDMI) |
| RSS Camera Control Port (USB-C) |
Expansion Port | Cold Shoe |
Operating Frequency | 2.400-2.484 GHz |
| 5.725-5.850 GHz |
Weight | 126 g (0.27 lbs) |
Dimensions | 82×63×24 mm (L×W×H) |
Transmitter Power (EIRP) | 2.400-2.484 GHz: |
| <25 dBm (FCC) |
| <20 dBm (CE/SRRC/MIC) |
| 5.725-5.850 GHz: |
| <25 dBm (FCC/SRRC) |
| <14 dBm (CE) |
Battery | Capacity: 2970 mAh |
| Compatible Charger: 5V/2A |
| Charging Time: Approx. 2.5 hours |
| Max Battery Life: Approx. 3.5 hours |
Transmission Range | 200 m (SRRC/FCC) [2] |
| 100 m (CE) [2] |
Latency | 60 ms |
Operating Current/Voltage | 900 mAh, 3.7V |
Operating Temperature | 0° to 45° C (32° to 113° F) |
| Notes | 1. Measured with the equipment in a level and stationary state, the gimbal balanced, three axes in an active state, and the battery only powering the gimbal. |
| 2. In open environments free of obstructions or interference. |
| |
